Specs
| Printing | Print Method | Direct thermal printing |
| Resolution | 203dpi | |
| Print Speed | Max.80mm/s | |
| Print Width | Max.72mm/576 dots | |
| Communication Interface | Standard micro-USB , Bluetooth 4.0 BLE/2.1+EDR (Dual Mode) Optional Wi-Fi（802.11b/g/n) | |
| Sensors | Printer cover open detection，Out-of-paper detection，Gap detection (transmission, fixed, middle) Black mark detection (reflective, right side of print back) TPH Temperature detection | |
| Software | HPRT Driver：Windows XP，Vista,7，8，10.Linux,Mac | |
| Paper | Paper Type | Thermal receipt paper |
| Paper Width | 55mm to 80mm(or 37mm to 63 mm) | |
| Paper Capacity | Max. Diameter 57mm | |
| Power | Input | AC 100~240V, 50/60Hz |
| Output | DC 5V, 1A | |
| Reliability | TPH Life | 50km |
| Levels of Protection | IP42 | |
| Drop Test Standard | 1.5m | |
| Hardware | Processor | ARMv7E-M Cortex-M7 32-bit RISC Processor |
| RAM | 32MB | |
| Flash | 256MB | |
| Physical Characteristics | Working Condition | 0°C ~ 55°C, 10% ~ 85% R.H, no-condensing |
| Storage Condition | -10°C ~ 65°C, 5% ～ 90% R.H, no-condensing | |
| Battery | Voltage | 7.4V |
| Capacity | 1800mAh | |
Features
• Adopt high-performance ARM Cortex-M7
• 80mm/s print speed
• Support CPCL and ZPL print protocol
• Equipped with 256 MB NAND FLASH
• Support TTF vector font
• Equipped with 1.3-inch OLED display
• Support Bluetooth 4.0/LE
• Optional Wi-Fi (802.11 b/g/n)
• Equipped with Micro-USB interface,support 5V/2A charge
