Features
• Equipped with 64 Kyocera industrial printheads, delivering production speeds of up to 1,800 m²/h
• Optimized printhead combination and control system maximize printhead performance for efficient handling of high-volume orders
• Supports acid, reactive, high-temperature disperse, and water-based pigment inks for a wide range of textile applications
• High-precision drive and ink supply systems deliver sharp details and consistent print quality for both rapid production and high-end customized designs
• Intelligent temperature control, nozzle calibration, belt cleaning, and moisturizing systems improve operational stability while helping reduce maintenance and operating costs
Specifications
| Model | DA208S EVO | |
| Name | High-speed Conveying-belt Direct to Fabric Digital Textile Printer | |
| Print Head | Kyocera Print Heads 64pcs | |
| Max. Print Width (mm) | 2000 | |
| Max. Cloth Feeding Width (mm) | 2050 | |
| Resolution（dpi） (Multiple modes available) | High speed mode 2 @508*600dpi|1pass | |
| Normal Speed Model 1 @400*1200dpi|2pass | Normal Speed Model 2 @508*1200dpi|2pass | |
| Normal Speed Model 3 @600*1200dpi|2pass | ||
| Quality mode 1 @400*1800dpi|3pass | Quality mode 2 @508*1800dpi|3pass | |
| Quality mode 3 @600*1800dpi|3pass | ||
| High precision mode 1 @600*2400dpi|4pass | High precision mode 2 @600*3600dpi|6pass | |
| High precision mode 3 @600*4800dpi|8pass | ||
| Maximum Allowable Roll Diameter of Rewinding Cloth Feed Holder (mm) | Φ500 | |
| Maximum Allowable Weight of Rewinding Cloth Feed Holder (kg) | 100 | |
| Maximum Allowable Roll Diameter of External Cloth Feed Holder A (mm) | Φ1600 (external fabric placer is optional). Supports fabric placement with fabric trolley | |
| Printing Speed（㎡ /hr） (Multiple modes available) | High speed mode 2 @508*600dpi|1pass: 1840 | High speed mode 3 @600*600dpi|1pass: 1632 |
| Normal Speed Model 1 @400*1200dpi|2pass: 1120 | Normal Speed Model 2 @508*1200dpi|2pass: 960 | |
| Normal Speed Model 3 @600*1200dpi|2pass: 816 | ||
| Quality mode 1 @400*1800dpi|3pass: 746 | Quality mode 2 @508*1800dpi|3pass:640 | |
| Quality mode 3 @600*1800dpi|3pass: 544 | ||
| High precision mode 1 @600*2400dpi|4pass: 408 | High precision mode 2 @600*3600dpi|6pass: 272 | |
| High precision mode 3 @600*4800dpi|8pass: 204 | ||
| Ink Type | Reactive ink,Acid ink,Pigment ink,Disperse ink,High temperature Disperse ink | |
| Ink Color (Color configuration according to customer demand and process) | C, M, Y, K, OR, R, B, G, P, GR, Lk, Lm, Lc, FM, FY | |
| Print Medium | Cotton, linen, silk, nylon, polyester, blended, elastic fabrics and new fiber woven and knitted fabrics | |
| Ink supply system and Degassing system | Automatic ink supply system, automatic degassing and automatic negative pressure system | |
| Printhead Cleaning and Maintenance | Automatic Cleaning & Moisturising System | |
| Over-height limit detection and Rectification | Auto detection of media exceeding the height limit, belt deviation rectification system | |
| Operation Interface | Front and rear touch screen controls | |
| Computer operating system andhardware requirements | Standard workstation computer suite | |
| RIP System | HPRT RIP,Neostampa | |
| Dimensions: L*W*H (mm) | 5593*4176*2452 | |
| Weight (kg) | 6000 | |
| Power consumption(KW) | Printer≦15kW | |
| Power Supply | Printer: AC380V|three-phase five wire system|30A（15KW）|50Hz/60Hz | |
| Compressed Air Supply | 0.6MPa|1m³/hr (Dry, no oil or water vapor) | |
| Water requirements | 0.4MPa|1000L/hr | |
| Operating Temperature | 20~30℃ | |
| Operating Humidity | 45%-75% (Non-condensing) | |
| Drying Option | Electric heating/steam heating/natural gas heating and other drying rooms | |
