Specs
| Technical Specifications | ||
| C-R1A | C-R1W | |
| Operating System | Android 8.1/Android 12 | Win7/Win10 |
| CPU | Rockchips RK3288/RK3568 | Intel ® Celeron TM J1900 Quad-core/N100 |
| RAM | 2 GB/4 GB | 8 GB |
| ROM | 16 GB/32 GB | 64 GB/128 GB/256 GB |
| Maximum Capacity | Max=6/15 kg | |
| Minimum Capacity | Min=40 g | |
| Number of Division | e=d=2/5 g | |
| Print Resolution | 203 dpi | |
| Print Length | 20~105 mm | |
| Media Type | Thermal receipt paper (including black mark) | |
| Media Width | Max.58 mm | |
| Media Outer Diameter | Max.70 mm | |
| Display | (Standard) Operator Screen: 14-inch capacitive touch screen | |
| (Optional)Customer Screen: 14-inch LED backlight display | ||
| Cutter | Standard | |
| External Interfaces | 1×Micro USB(Debug), 4×USB 2.0, 1×RJ12 Cash drawer 1×RJ45 LAN（10/100M）, 1×RJ11 Serial interface 1×Audio Microphone 2-in-1 Interface, 1×Power Interface | |
| Power Supply | Input: AC 100 V~240 V Output: DC 24 V/2.5 A | |
| Appearance and Material | Die-cast aluminium housing, food grade stainless steel tray | |
| Dimension(L×W×H) | 480 mm 426 mm×495 mm | |
Features
● Equipped with 58mm receipt printer, adaptive printing speed (up to 200mm/s), easy-disassembly module which is convenient to replace
● 14-inch dual screens with LED backlight and 1366×768-pixel screen resolution Multi-point touch capacitive operator screen
● Horizontally adjustable customer screen brings broader view space for customers
● With aerospace material and die-cast aluminum housing, which is waterproof, insect-proof and rust-proof.
● The fanless completely closed design prevents oil pollution from invading, which is quite applicable to the harsh environment
● Adjustable support knob makes it easy to adjust to the horizontal position without flipping the weighing body
